Product Specifications
| Manufacturer Part Number | GMG18915 |
| Diameter (Decimal Inch) | 0.7874" |
| Diameter (mm) | 20.00mm |
| Shank Diameter (Decimal Inch) | 0.7874" |
| Shank Diameter (mm) | 20.00mm |
| Length of Cut (Decimal Inch) | 3.1496" |
| Length of Cut (mm) | 80.00mm |
| Overall Length (Decimal Inch) | 5.9055" |
| Overall Length (mm) | 150.00mm |
| Corner Radius (Decimal Inch) | 0.0787" |
| Corner Radius (mm) | 2.00mm |
| Number of Flutes | 6 |
| Helix Angle | Variable |
| Series | GMG18 |
| Shank Style | Plain |
| Coating | Y-Coated |
| Material | Carbide |
| Cut Type | Center |
| Cutting Direction | Right |
| Length Type | Standard Length |
| Application | P, M, S |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
YG1
Mill Diameter (Decimal Inch):
0.7874"
Mill Diameter (Inch):
37/47"
Mill Diameter (mm):
20.00mm
Shank Diameter (Decimal Inch):
0.7874"
Shank Diameter (Inch):
37/47"
Shank Diameter (mm):
20.00mm
Length of Cut (Decimal Inch):
3.1496"
Length of Cut (mm):
80.00mm
Overall Length (Decimal Inch):
5.9055"
Overall Length (Inch):
5-48/53"
Overall Length (mm):
150.00mm
Number of Flutes:
6
Finish/Coating:
Y-Coating
Material:
Carbide
Cutting Direction:
Right
interval quantity:
1
