| Manufacturer Part Number | HPI89983 |
| Number of Flutes | 2 |
| Diameter (Decimal Inch) | 0.031" |
| Diameter (Inch) | 3/95" |
| Diameter (mm) | 0.80mm |
| Shank Diameter (Decimal Inch) | 0.157" |
| Shank Diameter (Inch) | 3/19" |
| Shank Diameter (mm) | 4.00mm |
| Length of Cut (Decimal Inch) | 0.026" |
| Length of Cut (Inch) | 1/39" |
| Length of Cut (mm) | 0.65mm |
| Overall Length (Decimal Inch) | 1.968" |
| Overall Length (Inch) | 1-31/32" |
| Overall Length (mm) | 50.00mm |
| Shank Type | Plain |
| Helix Angle | 35 Degree |
| Coating Process | C-Coated |
| Material | Carbide |
| Cut Type | Center |
| Cutting Direction | Right Hand |
| Product Type | Corner Radius End Mill |
