Product Specifications
| Manufacturer Part Number | HPK10160 |
| Diameter (Inch) | 17/27" |
| Diameter (Decimal Inch) | 0.630" |
| Diameter (mm) | 16.00mm |
| Shank Diameter (Inch) | 17/27" |
| Shank Diameter (Decimal Inch) | 0.630" |
| Shank Diameter (mm) | 16.00mm |
| Length of Cut (Inch) | 17/27" |
| Length of Cut (Decimal Inch) | 0.630" |
| Length of Cut (mm) | 16.00mm |
| LBS (Inch) | 1-20/77" |
| LBS (Decimal Inch) | 1.260" |
| LBS (mm) | 32.00mm |
| Overall Length (Inch) | 5-22/43" |
| Overall Length (Decimal Inch) | 5.512" |
| Overall Length (mm) | 140.00mm |
| Ball Nose (Decimal Inch) | 0.315" |
| Ball Nose (Inch) | 8.00mm |
| Neck Diameter (mm) | 15.70mm |
| Number of Flutes | 2 |
| Series | HPK10 |
| Shank Type | Plain |
| Helix Angle (Degree) | 30 Degree |
| Coating | C |
| Material | Carbide |
| Cutting Direction | Right Hand |
| Cut Type | Center |
| Product Type | Ball Nose End Mill-Neck |
