Product Specifications
| Manufacturer Part Number | L12DD360 |
| Thread Diameter (Inch) | M8 |
| Threads Per Inch | 1.25 TPI |
| Diameter (Inch) | 11/43" |
| Diameter (Decimal Inch) | 0.2560" |
| Diameter (mm) | 6.50mm |
| Shank Diameter (Inch) | 5/16" |
| Shank Diameter (Decimal Inch) | 0.3120" |
| Shank Diameter (mm) | 7.92mm |
| Thread Length (Inch) | 4/27" |
| Thread Length (Decimal Inch) | 0.1480" |
| Thread Length (mm) | 3.76mm |
| Overall Length (Inch) | 2-1/2" |
| Overall Length (Decimal Inch) | 2.5000" |
| Overall Length (mm) | 63.50mm |
| Neck (Inch) | 17/26" |
| Number of Flutes | 3 |
| Series | L12DD |
| Thread Series | M |
| Shank Style | Plain |
| Helix Angle | 15 Degree |
| Coating | TiAIN |
| Material | Carbide |
| Type | Metric Internal Thread-DIN13 |
| Application | P,K,N |
| Cutting Direction | Right |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
YG1
Thread Size (Inch):
M8
Threads Per Inch:
1.25 TPI
Cutter Diameter (Inch):
11/43"
Cutter Diameter (Decimal Inch):
0.2560"
Cutter Diameter (mm):
6.50mm
Shank Diameter (Inch):
5/16"
Shank Diameter (Decimal Inch):
0.3120"
Number of Flutes:
3
Finish/Coating:
TiAIN
Material:
Carbide
