Product Specifications
| EDP Number | SEME36105 |
| Diameter (Decimal Inch) | 0.4134" |
| Diameter (Inch) | 31/75" |
| Diameter (mm) | 10.50mm |
| Shank Diameter (Decimal Inch) | 0.4724" |
| Shank Diameter (Inch) | 43/91" |
| Shank Diameter (mm) | 12.00mm |
| Length of Cut (Decimal Inch) | 1.0236" |
| Length of Cut (Inch) | 1 2/85" |
| Length of Cut (mm) | 26.00mm |
| Overall Length (Decimal Inch) | 2.9528" |
| Overall Length (Inch) | 2-20/21" |
| Overall Length (mm) | 75.00mm |
| Shank Style | Plain |
| Helix Angle (Degree) | Variable |
| Coating | AlCrN |
| Number of Flutes | 4 |
| Cut Type | Center Cut |
| Corner Type | Square End |
| Series | SEME36 |
| Material | Carbide |
| Product Type | Square End Mill |
