| Manufacturer Part Number | T0C01502 |
| Size | 3/8" |
| Pitch | 24 TPI |
| Diameter (Decimal Inch) | 0.3750" |
| Diameter (mm) | 9.53mm |
| Overall Length (Decimal Inch) | 2.9400" |
| Overall Length (mm) | 74.68mm |
| Thread Length (Decimal Inch) | 0.7480" |
| Thread Length (mm) | 19.00mm |
| Square Length (Decimal Inch) | 0.4400" |
| Square Length (mm) | 11.18mm |
| Shank Diameter (Decimal Inch) | 0.3810" |
| Shank Diameter (mm) | 9.68mm |
| Square Size (Decimal Inch) | 0.2860" |
| Square Size (mm) | 7.26mm |
| Neck Diameter (Decimal Inch) | 0.3160" |
| Neck Diameter (mm) | 8.03mm |
| Drill Size (Decimal Inch) | 0.3371" |
| Drill Size (mm) | 8.56mm |
| Useable Length (Decimal Inch) | 1.2520" |
| Useable Length (mm) | 31.80mm |
| Length/Diameter | 2.0xD |
| Number of Flutes | 4 |
| Thread Class | 2B |
| Chamfer Length | 1.5P-2P |
| Blank Standard | 302A |
| Series | T0C01 |
| Thread Series | UNF |
| Coating | Bright |
| Material | Carbide |
| Coolant Through | No |
| Trade Name | YG Tap Cast |
| Shank Type | Square |
| Tap Type | Straight Flute |
| Chamfer Type | Bottoming |
| Product Type | Straight Flute Bottoming Tap |
