Product Specifications
| # Manufacturer Number | T2496643 |
| Diameter (Decimal Inch) | 0.6250" |
| Diameter (mm) | 15.88mm |
| Thread Size | 5/8" |
| Pitch | 11 TPI |
| Shank Diameter (Decimal Inch) | 0.4800" |
| Shank Diameter (mm) | 12.19mm |
| Overall Length (Decimal Inch) | 3.8100" |
| Overall Length (mm) | 96.77mm |
| Thread Length (Decimal Inch) | 1.0830" |
| Thread Length (mm) | 27.51mm |
| Square Length (Decimal Inch) | 0.5600" |
| Square Length (mm) | 14.22mm |
| Square Size (Decimal Inch) | 0.3600" |
| Square Size (mm) | 9.14mm |
| Neck Diameter (Decimal Inch) | 0.4690" |
| Neck Diameter (mm) | 0.00mm |
| Useable Length (Decimal Inch) | 1.8110" |
| Useable Length (mm) | 46.00mm |
| Drill Size (Decimal Inch) | 0.5423" |
| Drill Size (mm) | 13.78mm |
| Number of Flutes | 3 |
| Pitch Limit | H3 |
| Coolant Through | No |
| Shank Type | Square |
| Finish / Coating | Bright |
| Material | HSSE-V3 |
| Chamfer Length | 4P-5P |
| Chamfer Type | Plug |
| Product Type | Straight Flute Thread Mill |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
YG1
Threads Per Inch:
11 TPI
Material:
HSSE-V3
Thread Size (Inch):
5/8
Overall Length (Decimal Inch):
3.8100"
Shank Diameter (mm):
12.19mm
Number of Flutes:
3
Cutting Diameter (Decimal Inch):
0.6250"
Cutting Diameter (mm):
15.88mm
Finish/Coating:
Bright
interval quantity:
1
