Features
- Performs well on all materials
- Unique design works well on a wide range of materials thereby lowering the need to have multiple taps on hand for different materials.
Product Specifications
| Size Type | Metric |
| Thread Size | 5mmX.80mm |
| Thread Limit | D4 |
| Chamfer Style | Plug |
| No. of Flutes | 3 |
| Finish Coating | TiCN |
| Tool Material | High Speed Steel EX |
| Cutting Direction | Right Hand |
| Chamfer | 4-5 Lead |
| Flute Length | .531" |
| Coating | TiCN |
| Flute Shape | Straight Flute |
| Coolant Through | No |
| General Application | Through Hole Tapping |
| Helix Angle | 35 Degree |
| Hole Style | Through hole |
| Material To Be Machined | Multi Material |
| Overall Length | 2.38" |
| Series | T4-C |
| Limit | D4 |
| Shank Diameter | .194" |
| No. of Threads Per Inch | 0.8mm |
| Shank Type | Square Drive Shank |
| Size | 5mm |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
YG1
Thread Size (mm):
M5 x 0.8
Thread Limit:
D4
Number of Flutes:
3
Material:
High Speed Steel-EX
Finish/Coating:
TiCN
Through Coolant:
No
Travers SKU1:
12-679-353
Ships:
Same Business Day if Ordered by 12:30PM PT
interval quantity:
1
