| Manufacturer Part Number | T7406122 |
| Thread Size | #3 |
| Thread Size (Decimal Inch) | 0.126" |
| Thread Size (mm) | 3.20mm |
| Threads per Inch (TPI) | 48 |
| Thread Series | UNC |
| Pitch Limit | H2 |
| Chamfer Type | Bottoming |
| Chamfer Length | 1.5P-2P |
| Overall Length (Decimal Inch) | 1.937" |
| Overall Length (mm) | 49.20mm |
| Thread Length (Decimal Inch) | 0.236" |
| Thread Length (mm) | 5.99mm |
| Square Length (Decimal Inch) | 0.190" |
| Square Length (mm) | 4.83mm |
| Shank Diameter (Decimal Inch) | 0.141" |
| Shank Diameter (mm) | 3.58mm |
| Square Size (Decimal Inch) | 0.110" |
| Square Size (mm) | 2.79mm |
| Drill Size (Decimal Inch) | 0.109" |
| Drill Size (mm) | 2.76mm |
| Connection Size (Decimal Inch) | 0.141" x 0.110" |
| Connection Size (mm) | 3.58 x 2.79mm |
| Usable Length (Decimal Inch) | 0.630" |
| Usable Length (mm) | 16.00mm |
| Length / Diameter | 2.5 x D |
| Number of Flutes | 2 |
| Helix Angle (Degree) | 50 Degree |
| Coating | Bright |
| Material | HSS |
| Blank Standard | 322 |
| Series | T7406 |
| Product Type | Spiral Flute STI Tap |
