YG1 T7426407 | UNC 1/4" - 20 Size x 1.130" Thread Length x 0.318" Shank x 2.720" OAL H3 Plug Chamfer 3 Flute Bright Coated HSS T7426 Spiral Flute Tap

$16.10 $11.43
(You save $4.67)
Brand:
YG1
Thread Size (Inch):
1/4"
Thread Size (Decimal Inch):
0.2500"
Thread Size (mm):
6.35mm
Thread Limit:
H3
Number of Flutes:
3
Chamfer:
Plug
Finish/Coating:
Bright
Material:
HSS
Threads per Inch (TPI):
20
Overall Length (Decimal Inch):
2.7200"
Overall Length (mm):
69.09mm
interval quantity:
1
SKU:
15011998
UPC:
Weight:
0.05 LBS
Minimum Purchase:
1 unit
Shipping:
Calculated at Checkout

Product Specifications
Manufacturer Part NumberT7426407
Thread Size (Inch)1/4"
Thread Size (Decimal Inch)0.250"
Thread Size (mm)6.35mm
Threads per Inch (TPI)20
Thread SeriesUNC
Pitch LimitH3
Chamfer TypePlug
Chamfer Length4P-5P
Overall Length (Decimal Inch)2.720"
Overall Length (mm)69.09mm
Thread Length (Decimal Inch)1.130"
Thread Length (mm)28.70mm
Square Length (Decimal Inch)0.380"
Square Length (mm)9.65mm
Shank Diameter (Decimal Inch)0.318"
Shank Diameter (mm)8.08mm
Square Size (Decimal Inch)0.238"
Square Size (mm)6.05mm
Drill Size (Decimal Inch)0.264"
Drill Size (mm)6.70mm
Connection Size (Decimal Inch)0.318" x 0.238"
Connection Size (mm)8.08 x 6.05mm
Usable Length (Decimal Inch)1.130"
Usable Length (mm)28.70mm
Length / Diameter2.0 x D
Number of Flutes3
CoatingBright
MaterialHSS
Blank Standard322
SeriesT7426
Product TypeSpiral Flute Tap
