Product Specifications
| Diameter (Decimal Inch) | T7436502 |
| Diameter (Decimal Inch) | 0.4315" |
| Diameter (mm) | 10.96mm |
| Overall Length (Decimal Inch) | 3.1600" |
| Overall Length (mm) | 80.26mm |
| Thread Length (Decimal Inch) | 0.8660" |
| Thread Length (mm) | 22.00" |
| Square Length (Decimal Inch) | 0.8660" |
| Square Length (mm) | 22.00" |
| Shank Diameter (Decimal Inch) | 0.3230" |
| Shank Diameter (mm) | 8.20mm |
| Square Size (Decimal Inch) | 0.2420" |
| Square Size (mm) | 6.15mm |
| Drill Size (Decimal Inch) | 0.3858" |
| Drill Size (mm) | 9.80mm |
| Useable Length (Decimal Inch) | 1.4400" |
| Useable Length (mm) | 36.58mm |
| Length/Diameter | 3.0xD |
| Coolant Through | No |
| Tap Type | SPPT |
| Number Of Flutes | 3 |
| Size | 3/8 |
| Pitch | 24 TPI |
| Thread Series | UNF |
| Pitch Limit | H2 |
| Chamfer Type | Plug |
| Chamfer Length | 4P-5P |
| Finish | Bright |
| Material | HSS |
| Blank Standard | 322 |
| Product Type | Spiral Point Tap |
