Product Specifications
| # Manufacturer Number | T7A15508 |
| Diameter (Decimal Inch) | 0.4724" |
| Diameter (mm) | 12.00mm |
| Shank Diameter (Decimal Inch) | 0.3670" |
| Shank Diameter (mm) | 9.32mm |
| Overall Length (Decimal Inch) | 3.3800" |
| Overall Length (mm) | 85.85mm |
| Thread Length (Decimal Inch) | 1.6600" |
| Thread Length (mm) | 42.16mm |
| Square Length (Decimal Inch) | 0.4400" |
| Square Length (mm) | 11.18mm |
| Square Size (Decimal Inch) | 0.2750" |
| Square Size (mm) | 6.99mm |
| Drill Size (Decimal Inch) | 0.4098" |
| Useable Length (Decimal Inch) | 1.6600" |
| Useable Length (mm) | 42.16mm |
| Connecton (Decimal Inch) | 0.3670 x 0.2750" |
| Connecton (Decimal Inch) | 9.32 x 6.99mm |
| Pitch | 1.75 |
| Size | M12 |
| Number of Flute | 4 |
| Thread Series | M |
| Coating | Bright |
| Material | HSS |
| Product Type | Straight Flute Tap |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
YG1
Tap Type (Interrupted Thread Machine Tap, Machine Tap, Standard Hand Tap, etc):
Hand
Overall Length (Inch):
1-3/8";Overall Length (Decimal Inch)=3.3800""
Overall Length (mm):
85.85mm
Number of Flutes (2, 3, 4, etc.):
4
Material (Carbon-Tipped, Carbon Steel, Cobalt, etc):
HSS
Finish/Coating (AL2 Plus, AlCrN, etc):
Bright
Chamfer (Bottoming, Modified Bottoming, Plug, Semi-Bottoming, Tape, etc):
Bottoming
