| Manufacturer Part Number | T7R02283 |
| Diameter (Decimal Inch) | 0.1640" |
| Diameter (mm) | 4.17mm |
| Pitch | 32 TPI |
| Size | #8 |
| Shank Diameter (Decimal Inch) | 0.1680" |
| Shank Diameter (mm) | 4.27mm |
| Overall Length (Decimal Inch) | 2.1300" |
| Overall Length (mm) | 54.10mm |
| Thread Length (Decimal Inch) | 0.5000" |
| Thread Length (mm) | 12.70mm |
| Square Length (Decimal Inch) | 0.2500" |
| Square Length (mm) | 6.35mm |
| Square Size (Decimal Inch) | 0.1310" |
| Square Size (mm) | 3.33mm |
| Drill Size (Decimal Inch) | 0.1502" |
| Drill Size (mm) | 3.81mm |
| Number of Lobes | 4 |
| Number of Grooves | 1 |
| Length Diameter | 3.0 x D |
| Shank Type | Square |
| Coating | TICN |
| Material | HSS |
| Thread Series | UNC |
| Series | T7R02 |
| Product Type | Thread Forming Tap |
