| Manufacturer Part Number | TE640 |
| Thread Size (Inch) | 5/8" |
| Threads per Inch (TPI) | 11 |
| Thread Series | UN |
| Thread Size (Decimal Inch) | 0.470" |
| Thread Size (mm) | 11.94mm |
| Shank Diameter (Inch) | 1/2" |
| Shank Diameter (Decimal Inch) | 0.500" |
| Shank Diameter (mm) | 12.70mm |
| Thread Length (Decimal Inch) | 1.250" |
| Thread Length (mm) | 31.75mm |
| Overall Length (Inch) | 3-1/2" |
| Overall Length (Decimal Inch) | 3.500" |
| Overall Length (mm) | 88.90mm |
| Shank Type | Plain |
| Helix Angle (Degree) | 15 Degree |
| Number of Flutes | 4 |
| Coating | TiAN |
| Material | Carbide |
| Application | P, K, N |
| Series | TE |
| Cutting Direction | Right Hand |
| Product Type | Helical Flute Thread Mill |
