Product Specifications
| EDP Number | WL026SNR |
| Shoulder Diameter (Inch) | 2-3/4" |
| Shoulder Diameter (mm) | 69.9mm |
| Shoulder Diameter (Decimal Inch) | 2.752" |
| Bore Diameter (Inch) | 1" |
| Bore Diameter (mm) | 25.4mm |
| Nose Diameter (mm) | 55.5mm |
| Bore Diameter (Decimal Inch) | 1" |
| Nose Diameter (Inch) | 2-3/16" |
| Nose Diameter (Decimal Inch) | 2.185" |
| Gage Length (Decimal Inch) | 3.189" |
| Gage Length (Inch) | 3-3/16" |
| Gage Length (mm) | 81mm |
| Maximum Tool Depth inch (l2) | 1.89" |
| Maximum Tool Depth fraction (l2) | 1-7/8" |
| Maximum Tool Depth metric (L2) | 48.01mm |
| Grade | M16X1.0 |
| Taper Accuracy | AT3 |
| Grade Value | 2.5 |
| RPM | 25000 |
| Run Out (at 3D) | <0.00012" |
| Coolant system | AD/B |
| Taper # | CAT50 |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
YG1
Bore Diameter (Decimal Inch):
1.0000"
Bore Diameter (mm):
25.40mm
Nose Diameter (Decimal Inch):
2.1850"
Nose Diameter (mm):
55.50mm
Shoulder Diameter (Decimal Inch):
2.7520"
Shoulder Diameter (mm):
69.90mm
Speed (RPM):
25000 RPM
