Product Specifications
| # MFG | 564046 |
| Adjustment Dial (Inch) | 0.0001" |
| Adjustment Dial (mm) | 0.002mm |
| Body Diameter (Inch) | 2.48" |
| Body Diameter (mm) | 63mm |
| Body Length (Inch) | 3.445" |
| Body Length (mm) | 87.5mm |
| Male Major | 63 |
| Male Minor | 36 |
| Maximum Diameter (Inch) | 4.055" |
| Maximum Diameter (mm) | 103mm |
| Minimum Diameter (Inch) | 3.228" |
| Minimum Diameter (mm) | 82mm |
| Offset (Inch) | 0.827" |
| Offset (mm) | 21mm |
| Material | Aluminum |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Allied Machine and Engineering
Body Diameter (Decimal Inch):
2.4800"
Body Diameter (mm):
63.00mm
Maximum Diameter (Decimal Inch):
4.0550"
Maximum Diameter (mm):
103.00mm
Minimum Diameter (Decimal Inch):
3.2280"
Minimum Diameter (mm):
82.00mm
Body Length (Decimal Inch):
3.4450"
Body Length (mm):
88.00mm
Material:
Aluminum
interval quantity:
1
