Name: Dormer 7648868 | 19.05mm Diameter x 19.05mm Shank x 1-1/2" Maximum Depth of Cut x 101.60mm OAL x 30 Degree Helix Angle 4 Flute TiAlN Coated HM S238 Ball End Mill
Brand: Dormer
SKU: 25140738
Price: 218.4 USD
Availability: InStock

Dormer 7648868 | 19.05mm Diameter x 19.05mm Shank x 1-1/2" Maximum Depth of Cut x 101.60mm OAL x 30 Degree Helix Angle 4 Flute TiAlN Coated HM S238 Ball End Mill

$364.00 $218.40

(You save $145.60)

Brand:

Dormer

Mill Diameter (Inch):

3/4"

Mill Diameter (Decimal Inch):

0.7500"

Mill Diameter (mm):

19.05mm

Number of Flutes:

Material:

Overall Length (Inch):

Overall Length (Decimal Inch):

4.0000"

Overall Length (mm):

101.60mm

Shank Diameter (Inch):

3/4"

Shank Diameter (Decimal Inch):

0.7500"

Shank Diameter (mm):

19.05mm

Finish/Coating:

TiAlN

Helix Angle:

30 Degree

interval quantity:

SKU:

25140738

UPC:

7320760849156

Weight:

0.80 LBS

Minimum Purchase:

1 unit

Shipping:

Calculated at Checkout

Features
Reviews
Other Details

Part of Dormer's extensive range of carbide cutters, S238 4-flute end mills have a ball nose, designed for high performance contouring of complex surfaces, and can be used for ramping, plunging and profile milling in stainless steels, steels and cast irons. For superior performance and extended tool live they are manufactured from premium carbide, and have an aluminium titanium nitride coating which prevents workpiece material from sticking to the cutting edges of the tool so you get clean, accurate results. S238 4-flute ball nose milling cutters come with an extra long shank for good reach and high rigidity for profile milling.

Product Specifications

Connection Diameter (Inch)	0.75"
Cutting Diameter (Inch)	0.75"
Overall Length (Inch)	4"
Material Code	HM
No of Flute	4
Flute Helix Angle	30
Coating	TiAlN
Surface Color	Black-Deep Purple
Country of origin	United States of America
