Features:
- Hard milling for materials up to 66 HRC
- External
Product Specifications
| Decimal Size (Inch) | 0.3125" |
| End Style | Ball Nose |
| End Type | Finisher |
| Size | 5/16" |
| Applicable Material | High Tensile Strength Materials, Hardened Steels |
| Type | Ball Nose |
| Length Group | Stub Length |
| Features: | Tight tolerance high performance milling. Very stable milling properties |
| Coating | TIALN |
| Material | Carbide |
| Number of Flutes | 4 |
| Helix Angle (Degrees) | 30 Degree |
| Shank Diameter (Inch) | 5/16" |
| Shank Tolerance | h6 |
| Shank Style | HA |
| Overall Length (Inch) | 2-1/2" |
| Flute Length (Inch) | 9/32" |
| Flute Direction | Right Hand |
| Application | Finisher |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Ships:
From Manufacturer
