Fullerton Tool 39611 | 1/2" Diameter x 1/2" Shank x 1" LOC x 3" OAL 4 Flute TiAlN Solid Carbide Radius End Mill

$176.74 $111.35
(You save $65.39)
Ships:
From Partner Facility
Brand:
Fullerton Tool
Mill Diameter (Inch):
1/2"
Number of Flutes:
4
Length of Cut (Inch):
1"
Length of Cut (Decimal Inch):
1"
Length of Cut (mm):
25.40mm
Shank Diameter (Inch):
1/2"
Shank Diameter (Decimal Inch):
0.5000"
Shank Diameter (mm):
12.70mm
Overall Length (Inch):
3"
Overall Length (Decimal Inch):
3"
Overall Length (mm):
76.20mm
Material:
Solid Carbide
Finish/Coating:
TiAlN
Single or Double End:
Single
Series:
3995 Hogger
Ships:
From Partner Facility
SKU:
25002850
UPC:
Weight:
0.35 LBS
Shipping:
Free Shipping
Fullerton Tool 39611 | 1/2" Diameter x 1/2" Shank x 1" LOC x 3" OAL 4 Flute TiAlN Solid Carbide Radius End Mill

Features

  • The 3995 Hogger is a high performance end mill available with 3, 4, or 5-flutes
  • It is designed as a rougher for high volume material removal in titanium, inconel, waspaloy, and other difficult-to-machine aerospace alloys
  • The 3995 Hogger is stocked with TiAlN coating

Product Specifications
Cutting Diameter (Decimal Inch) 0.5000"
Cutting Diameter (mm) 12.70mm
Cutting Diameter (Inch) 1/2"
Cutting Flute Length (Decimal Inch) 1"
Cutting Flute Length (mm) 25.40mm
Cutting Flute Length (Inch) 1"
Shank Diameter (Decimal Inch) 0.5000"
Shank Diameter (mm) 12.70mm
Shank Diameter (Inch) 1/2"
Overall Length (Decimal Inch) 3.0000"
Overall Length (mm) 76.20mm
Overall Length (Inch) 3"
Coating/Finish TIALN
Metric/Inch Inch
Number of Flutes 4
Helix Angle (Degrees) 30
Flute Spiral Direction Right Hand
Direction of Cut Right Hand
Point End Type Corner Radius
End Type Character Designation R
Radius (Decimal Inch) 0.0625"
Radius (mm) 1.59mm
End Type Single End
Coolant Through Non Coolant Through
Weldon Flat Yes
Length Standard
Length Designator SD
