Features
- Improves rigidity and reduces vibration allowing for increased feed rates and increased tool life
- DIN coolant option - standard
- All ground body
- CAT40 premium balanced to 30,000 RPM
- CAT50 premium balanced to 25,000 RPM
- Comes complete with certificate
Product Specifications
| Manufacturer Part Number | 521458 |
| Collet System | ER |
| Collet Series | ER32 |
| Shank Type | Taper Shank |
| Taper Size | CAT50 |
| Projection (Decimal Inch) | 8" |
| Minimum Collet Capacity (Decimal Inch) | 0.078" |
| Maximum Collet Capacity (Decimal Inch) | 0.787" |
| Balanced to (RPM) | 25000 RPM |
| Collet Nut Diameter (Decimal Inch) | 1.97" |
| Seat Depth (Decimal Inch) | 1.34" |
| Tightening Torque (Nm) | 169.5 |
| Product Type | Collet Chuck |
