Features
- Weldon shank
- Precision ground surfaces
- Compact length
- Provide additional mating flexibility
- Provides axial float
- Adjustable entry force
Product Specifications
| Manufacturer Part Number | 534534 |
| Shank Type | Straight Shank |
| Shank Diameter (Inch) | 1-1/2" |
| Projection (Decimal Inch) | 5.55" |
| Tapping Style | Tension/Compression |
| Nose Diameter (Decimal Inch) | 2" |
| ANSI Tap (Inch) | 13/16-1-3/8" |
| System | #2 |
| Shank Length (Decimal Inch) | 2.69" |
| Tension/Compression (Inch) | 0.85/0.49" |
| NPT (Inch) | 1/4-1/2" |
| Product Type | Tapping Chuck |
