| Drill Diameter (Decimal Inch) | 0.1562" |
| Drill Diameter (Inch) | 5/32" |
| Angle Per Side | 60 Degrees |
| Included Angle | 120 Degree |
| Flute Length (Decimal Inch) | 0.3750" |
| Flute Length (Inch) | 3/8" |
| Shank Diameter (Decimal Inch) | 0.1875" |
| Shank Diameter (Inch) | 3/16" |
| Overall Length (Decimal Inch) | 2.0000" |
| Overall Length (Inch) | 2" |
| Finish/Coating | AlTiN |
| Through Coolant | No |
| Material | Solid Carbide |
| Number of Flutes | 2 |
| LOC Multiple | (2x) |
| Web Thickness (Decimal Inch) | 0.0110" |
| Type | II |
| Single or Double | Single |
