Product Specifications
| Manufacturer Part Number | 700103 |
| Cutter Diameter (Inch) | 7/32" |
| Cutter Diameter (Decimal Inch) | 0.219" |
| Drill Diameter (Inch) | 7/64" |
| Drill Diameter(Decimal Inch) | 0.109" |
| Flute Length (Decimal Inch) | 0.273" |
| Overall Length (Inch) | 2-1/2" |
| Overall Length (Decimal Inch) | 2.500" |
| Point Angle (Degree) | 130 Degree |
| Number of Flute | 2 |
| Size | 3" |
| Shank Diameter (Inch) | 1/4" |
| Shank Diameter (Decimal Inch) | 0.250" |
| Coating | Uncoated |
| Drill Length (Decimal Inch) | 0.164" |
| Product Type | Combined Drill Counterbore |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Harvey Tool
Overall Length (Inch):
2-1/2"
Overall Length (Decimal Inch):
2.5000"
Overall Length (mm):
63.50mm
Finish/Coating:
Uncoated
interval quantity:
1
