These unique tools, Harvey Tool's End Mills for Plastics - Square Downcut - 2 Flute, prevent fraying and chip-out on the top of the workpiece, resist lifting on vacuum tables, and are designed with large flute valleys to maximize chip removal and performance.
- High rake, high relief design with large flute valley maximizes chip removal and performance
- Prevents fraying and chip-out on the top of the workpiece
- Prevents lifing on vacuum tables
- CNC ground in the USA
- Solid carbide
Product Specifications
| Tool Number | 775831 |
| Cutter Diameter (Inch) | 0.0310" (1/32) |
| Length of Cut (Inch) | 0.0930" (3/32) |
| Overall Length (Inch) | 1.5000" (1-1/2) |
| Flutes | 2 |
| LOC Multiple | 3x |
| Shank Diameter (Inch) | 0.1250" (1/8) |
| Coating | Uncoated |
