| Drill Diameter (Inch) | 7/64" |
| Drill Diameter (Decimal Inch) | 0.1094" |
| Length of Cut (Decimal Inch) | 0.1820" |
| Drill Length (Inch) | 7/64" |
| Drill Length (Decimal Inch) | 0.1090" |
| Overall Length (Inch) | 2" |
| Overall Length (Decimal Inch) | 2.0000" |
| Angle per Side | 60 Degree |
| Included Angle | 120 Degree |
| Point Angle | 120 Degree |
| Number of Flutes | 2 |
| Size (Inch) | #3 |
| Shank Diameter (Inch) | 1/4" |
| Shank Diameter (Decimal Inch) | 0.2500" |
| Metric (Yes/No) | No |
| Center Cutting (Yes/No) | No |
| Chip Breaker (Yes/No) | No |
| Finish/Coating | AlTiN |
| Double Ended (Yes/No) | Yes |
| Weldon Flat (Yes/No) | No |
| Coolant Through (Yes/No) | No |
