Product Specifications
| Cutter Diameter (Decimal Inch) | 0.0390" |
| Neck Diameter (Decimal Inch) | 0.0370" |
| Length of Cut (Inch) | 1/32" |
| Length of Cut (Decimal Inch) | 0.0310" |
| Overall Reach (Inch) | 5/32" |
| Overall Reach (Decimal Inch) | 0.1560" |
| Overall Length (Inch) | 1/4" |
| Overall Length (Decimal Inch) | 0.2500" |
| Number of Flutes | 2 |
| LOC Multiple | 0.8x |
| Reach Multiple | 4x |
| Shank Diameter (Inch) | 1/4" |
| Shank Diameter (Decimal Inch) | 0.2500" |
| Metric (Yes/No) | No |
| Center Cutting (Yes/No) | No |
| Chip Breaker (Yes/No) | No |
| Finish/Coating | AlTiN Nano |
| Double Ended (Yes/No) | No |
| Weldon Flat (Yes/No) | No |
| Coolant Through (Yes/No) | No |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Harvey Tool
Mill Diameter (Decimal Inch):
0.0390"
Number of Flutes:
2
Length of Cut (Inch):
1/32"
Length of Cut (Decimal Inch):
0.0310"
Overall Reach (Inch):
5/32"
Overall Reach (Decimal Inch):
0.1560"
Material:
Carbide
Finish/Coating:
AlTiN Nano
Shank Diameter (Inch):
1/4"
Shank Diameter (Decimal Inch):
0.2500"
Application:
Hardened Steels
Single or Double End:
Single
Overall Length (Inch):
1/4"
Overall Length (Decimal Inch):
0.2500"
Center Cutting:
No
Ships:
From Partner Facility
