| Length of Cut (Decimal Inch) | 0.1620" |
| Overall Length (Inch) | 2" |
| Overall Length (Decimal Inch) | 2.0000" |
| Tip Diameter (Decimal Inch) | 0.0100" |
| Angle per Side | 30 Degree |
| Included Angle | 60 Degree |
| Number of Flutes | 2 |
| Type | I |
| Shank Diameter (Inch) | 3/16" |
| Shank Diameter (Decimal Inch) | 0.1875" |
| Metric (Yes/No) | No |
| Center Cutting (Yes/No) | No |
| Chip Breaker (Yes/No) | No |
| Finish/Coating | Uncoated |
| Double Ended (Yes/No) | Yes |
| Weldon Flat (Yes/No) | No |
| Coolant Through (Yes/No) | No |
