Product Specifications
| Milling Diameter (Inch) | 3/16" |
| Milling Diameter (Decimal Inch) | 0.1875" |
| Number of Flutes | 2 |
| Length Of Cut (Decimal Inch) | 0.1500" |
| Overall Reach (Decimal Inch) | 1.9400" |
| Finish/Coating | AlTiN Nano |
| Shank Diameter (Inch) | 1/4" |
| Shank Diameter (Decimal Inch) | 0.2500" |
| Single or Double End | Single |
| Overall Length (Inch) | 4" |
| Overall Length (Decimal Inch) | 4.0000" |
| Center Cutting (Yes/No) | Yes |
| Tapered Reach (Decimal Inch) | 1.9400" |
| Neck Angle | 1 Degrees |
| LOC Multiple | 0.8x |
| Type | II |
| Metric (Yes/No) | No |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Harvey Tool
Mill Diameter (Inch):
3/16"
Mill Diameter (Decimal Inch):
0.1875"
Number of Flutes:
2
Length of Cut (Decimal Inch):
0.1500"
Shank Type:
Reduced
Overall Reach (Decimal Inch):
1.9400"
Material:
Carbide
Finish/Coating:
AlTiN Nano
Shank Diameter (Inch):
1/4"
Shank Diameter (Decimal Inch):
0.2500"
Application:
Medium Alloy Steels
Single or Double End:
Single
Overall Length (Inch):
4"
Overall Length (Decimal Inch):
4.0000"
Center Cutting:
Yes
Ships:
From Partner Facility
