- Oversized, common shanks to maintain strength, stiffness, and accuracy
- Straight flutes for through and blind hole applications
- h6 shank tolerance for high precision tool holders
- CNC ground in the USA
- Solid carbide
Product Specifications
| Tool Number | RSB3125-C3 |
| Reamer Diameter (Inch) | 0.3125" (5/16) |
| Neck Diameter (Inch) | 0.3025" |
| Overall Reach (Inch) | 3.0000" (3) |
| Overall Length (Inch) | 6.0000" (6) |
| Chamfer Length (Inch) | 0.0250" |
| Angle per Side | 45 |
| Included Angle | 90 |
| Flutes | 6 |
| LOC Multiple | 4x |
| Reach Multiple | 10x |
| Margin Length (Inch) | 1.1250" (1-1/8) |
| Shank Diameter (Inch) | 0.3750" (3/8) |
| Coating | C3 |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Harvey Tool
Reamer Diameter (Inch):
5/16"
Reamer Diameter (Decimal Inch):
0.3125"
Neck Diameter (Decimal Inch):
0.3025"
Shank Diameter (Inch):
3/8"
Shank Diameter (Decimal Inch):
0.3750"
Shank Diameter (mm):
9.53mm
Overall Length (Inch):
6"
Overall Length (Decimal Inch):
6.0000"
Chamfer Length (Decimal Inch):
0.0250"
Overall Reach (Inch):
3"
Overall Reach (Decimal Inch):
3.0000"
Included Angle:
90 Degree
Finish/Coating:
C3
Number of Flutes:
6
