Product Specifications
| Manufacturer Part Number | RSB3760-C3 |
| Reamer Diameter (Decimal Inch) | 0.376" |
| Neck Diameter (Decimal Inch) | 0.366" |
| Overall Reach (Inch) | 3-1/2" |
| Overall Reach (Decimal Inch) | 3.500" |
| Overall Length (Inch) | 6" |
| Overall Length (Decimal Inch) | 6.000" |
| Chamfer Length (Decimal Inch) | 0.030" |
| Angle per Side (Degree) | 45 Degree |
| Included Angle (Degree) | 90 Degree |
| Number of Flutes | 6 |
| Length of Cut Multiple | (3x) |
| Reach Multiple | (9x) |
| Margin Length (Inch) | 1-1/4" |
| Margin Length (Decimal Inch) | 1.250" |
| Shank Diameter (Inch) | 1/2" |
| Shank Diameter (Decimal Inch) | 0.500" |
| Coating | AlTiN |
| Material | Carbide |
| Product Type | Miniature Reamer |
