Helical Solutions 84796 | H35ALV-C-020-30125-R.030 1/8" Diameter x 1/8" Shank x 1/4" LOC x 1-1/2" OAL x 0.0300" Radius 3 Flute Uncoated Solid Carbide Corner Radius End Mill

$20.80
Brand:
Helical Solutions
Mill Diameter (Inch):
1/8"
Mill Diameter (Decimal Inch):
0.1250"
Mill Diameter (mm):
3.18mm
Number of Flutes:
3
Corner Radius (Inch):
1/32"
Corner Radius (Decimal Inch):
0.0300"
Corner Radius (mm):
0.76mm
Length of Cut (Inch):
1/4"
Length of Cut (Decimal Inch):
0.2500"
Length of Cut (mm):
6.35mm
Finish/Coating:
UN
Shank Diameter (Inch):
1/8"
Shank Diameter (Decimal Inch):
0.1250"
Shank Diameter (mm):
3.18mm
Overall Length (Inch):
1-1/2"
Overall Length (Decimal Inch):
1.5000"
Overall Length (mm):
38.1mm
SKU:
25188535
Weight:
1.23 LBS
Shipping:
Calculated at Checkout
84796

The H35ALV-C-3's specialized variable pitch and chipbreaker geometry allows for reduced harmonics and increased material removal rates. Enjoy prolonged tool life and boosted shop efficiency by utilizing this tool with High Efficiency Milling toolpaths.

  • Designed for outstanding performance and accelerated metal removal rates in aluminum and non-ferrous materials
  • Engineered with optimized variable pitch and chipbreaker geometry for reduced harmonics and elevated material removal rates
  • Unique tool design requires less torque and horsepower
  • Excellent performance in High Efficiency Milling (HEM)
  • Unique "3 teeth-to-center" end geometry for ramping applications
  • h6 shank tolerance for high precision tool holders
  • Zplus coating offers higher hardness and added lubricity for maximum performance
  • Solid carbide end mills
  • CNC ground in the USA

Product Specifications
Cutter Diameter (Inch)0.1250" (1/8)
Length of Cut (Inch)0.2500" (1/4)
Overall Length (Inch)1.5000" (1-1/2)
Corner Radius (Inch)0.0300"
No of Flutes3
Shank Diameter (Inch)0.1250" (1/8)
Finish/CoatingUncoated
Center Cutting (Yes/No)Yes
Chip Breaker (Yes/No)Yes

Warning:

This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.

For more information, visit www.P65Warnings.ca.gov

Brand:
Helical Solutions
Mill Diameter (Inch):
1/8"
Mill Diameter (Decimal Inch):
0.1250"
Mill Diameter (mm):
3.18mm
Number of Flutes:
3
Corner Radius (Inch):
1/32"
Corner Radius (Decimal Inch):
0.0300"
Corner Radius (mm):
0.76mm
Length of Cut (Inch):
1/4"
Length of Cut (Decimal Inch):
0.2500"
Length of Cut (mm):
6.35mm
Finish/Coating:
UN
Shank Diameter (Inch):
1/8"
Shank Diameter (Decimal Inch):
0.1250"
Shank Diameter (mm):
3.18mm
Overall Length (Inch):
1-1/2"
Overall Length (Decimal Inch):
1.5000"
Overall Length (mm):
38.1mm
