| Manufacturer Part Number | 930-003-057 |
| Cutting Diameter (Decimal Inch) | 0.010" |
| Maximum Axial Depth of Cut (Decimal Inch) | 0.015" |
| Connection Diameter (Decimal Inch) | 0.125" |
| Overall Length (Decimal Inch) | 2.500" |
| Functional Length (Decimal Inch) | 0.125" |
| Length of Shank (Decimal Inch) | 2.318" |
| Number of Flutes | 3 |
| Cutting Direction | Right Hand |
| Material | Carbide |
| Coating | Amorphous Diamond |
| Connection Type | Shank |
| Product Type | Square End Mill |
