| Manufacturer Part Number | 956-000-062 |
| Cutting Diameter (Decimal Inch) | 1.000" |
| Connection Diameter (Decimal Inch) | 1.000" |
| Overall Length (Decimal Inch) | 8.270" |
| Functional Length (Decimal Inch) | 2.520" |
| Length of Shank (Decimal Inch) | 5.480" |
| Usable Length (Decimal Inch) | 0.270" |
| Cutting Edge Count | 2 |
| Included Angle (Degree) | 118 Degree |
| Included Angle 1 (Degree) | 82 Degree |
| Connection Type | Shank |
| Cutting Direction | Right Hand |
| Material | HSS-Co |
| Product Type | Spotting Drill |
