Features:
| EDP Number | 8805056 |
| Shank Width (Decimal Inch) | 0.7500" |
| Shank Width (mm) | 25.40mm |
| Max Depth of Cut (Decimal Inch) | 0.2165" |
| Max Depth of Cut (mm) | 5.50mm |
| Cutting Width (Decimal Inch) | 0.1378 - 0.1890" |
| Cutting Width (mm) | 3.50 - 4.80mm |
| Cutting Width Minimum (Decimal Inch) | 0.1378" |
| Cutting Width Minimum (mm) | 3.50mm |
| Cutting Width Maximum (Decimal Inch) | 0.1890" |
| Cutting Width Maximum (mm) | 4.80mm |
| Shank Height (Decimal Inch) | 1.0000" |
| Shank Height (mm) | 25.40mm |
| Application | Shallow Grooving |
| Grooving Type | External Grooving |
| Hand | Right Hand |
| Insert Holding Method | Lever Lock / Lock Pin |
| Material | Steel |
