Features:
| EDP Number | OTM86131 |
| Maximum Depth of Cut (Decimal Inch) | 0.4000" |
| Maximum Depth of Cut (mm) | 15.57mm |
| Cutting Width (Decimal Inch) | 0.4000" |
| Cutting Width (mm) | 10.16mm |
| Cutting Width Minimum (Decimal Inch) | 0.4000" |
| Cutting Width Minimum (mm) | 10.16mm |
| Cutting Width Maximum (Decimal Inch) | 0.4000" |
| Cutting Width Maximum (mm) | 10.16mm |
| Cutting Diameter (Decimal Inch) | 1.8000 - 1.8000" |
| Cutting Diameter (mm) | 45.72 - 45.72mm |
| Cutting Diameter Maximum (Decimal Inch) | 1.8000" |
| Cutting Diameter Maximum (mm) | 45.72mm |
| Connection Diameter (Decimal Inch) | 0.7500" |
| Connection Diameter (mm) | 19.05mm |
| Tool Entering Angle ( Degree) | 45 Degree |
| Application | Chamfering | Countersinking | Facing |
| Hand | Right Hand |
| Insert Holding Method | Screw |
| Material | Steel |
| Number of Flutes | 2 |
| Number of Inserts | 2 |
| Shank Type | Standard Length |
