Features:
- 90 Degree Lead angle face mill
- Application: shouldering, facing, slotting
- General purpose 90 Degree milling cutter
- Compatible with (4) XPMT15T304, XPMT15T308, XPMT15T316 style inserts
Product Specifications
| EDP Number | OTM86428 |
| Maximum Depth of Cut (Decimal Inch) | 0.6000" |
| Maximum Depth of Cut (mm) | 15.24mm |
| Cutting Diameter (Decimal Inch) | 3.0000" |
| Cutting Diameter (mm) | 76.20mm |
| Cutting Diameter Minimum (Decimal Inch) | 3.0000" |
| Cutting Diameter Minimum (mm) | 76.20mm |
| Cutting Diameter Maximum (Decimal Inch) | 3.0000" |
| Cutting Diameter Maximum (mm) | 76.20mm |
| Cutting Diameter Maximum (mm) | 1.0000" |
| Connection Bore Diameter (mm) | 25.40mm |
| Contact Surface Diameter Machine Side (Decimal Inch) | 2.5000" |
| Contact Surface Diameter Machine Side (mm) | 63.50mm |
| Tool Entering Angle ( Degree) | 90 Degree |
| Application | Facing, Shouldering, Slotting |
| Cutter Pitch | Standard Pitch |
| Hand | Right Hand |
| Insert Holding Method | Screw |
| Material | Steel |
| Number of Flutes | 4 |
| Number of Inserts | 4 |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Kyocera Precision Tools
Cutting Diameter (Inch):
3"
Cutting Diameter (Decimal Inch):
3.0000"
Cutting Diameter (mm):
76.20mm
Maximum Depth of Cut (Inch):
19/32"
Maximum Depth of Cut (Decimal Inch):
0.6000"
Maximum Depth of Cut (mm):
15.24mm
Arbor Hole Diameter (Inch):
1"
Arbor Hole Diameter (Decimal Inch):
1.0000"
Arbor Hole Diameter (mm):
25.40mm
Series:
FM
Cutter Style:
FM
Number of Cutter Inserts:
4
