Features:
- Polygon taper design and dual contact between the taper and the flange face for high rigidity
- High precision with locational accuracy +/-2mm
- Distributes cutting forces evenly between 3 faces for enhanced rigidity and center accuracy
- Compatible with GBA43L inserts
Product Specifications
| EDP Number | THC14770 |
| Max Depth of Cut (Decimal Inch) | 0.2165" |
| Max Depth of Cut (mm) | 5.50mm |
| Cutting Width (Decimal Inch) | 0.0311 - 0.1969" |
| Cutting Width (mm) | 0.79 - 5.00mm |
| Cutting Width Minimum (Decimal Inch) | 0.0311" |
| Cutting Width Minimum (mm) | 0.79mm |
| Cutting Width Maximum (Decimal Inch) | 0.1969" |
| Cutting Width Maximum (mm) | 5.00mm |
| Contact Surface Diameter Machine Side (Decimal Inch) | 1.9685" |
| Contact Surface Diameter Machine Side (mm) | 50.00mm |
| Application | External Shallow Grooving |
| Grooving Type | External Grooving |
| Hand | Left Hand |
| Insert Holding Method | Top Clamp |
| Material | Steel |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Kyocera Precision Tools
Toolholder Type:
External Grooving
Hand of Holder:
Left-Hand
Maximum Depth of Cut (Decimal Inch):
0.2165"
Maximum Depth of Cut (mm):
5.50mm
Minimum Groove Width (Decimal Inch):
0.0311"
Minimum Groove Width (mm):
0.79mm
Maximum Groove Width (Decimal Inch):
0.1969"
Maximum Groove Width (mm):
5.00mm
Toolholder Style:
KPC
Series:
KPC;Through Coolant=No"
