Features:
| EDP Number | THN08423 |
| Maximum Depth of Cut (Decimal Inch) | 0.1969" |
| Maximum Depth of Cut (mm) | 6.00mm |
| Cutting Diameter (Decimal Inch) | 2.4803 - 2.5591" |
| Cutting Diameter (mm) | 63.00 - 65.00mm |
| Cutting Diameter Minimum (Decimal Inch) | 2.4803" |
| Cutting Diameter Minimum (mm) | 63.00mm |
| Cutting Diameter Maximum (Decimal Inch) | 2.5591" |
| Cutting Diameter Maximum (mm) | 65.00mm |
| Cutting Diameter Maximum (mm) | 0.8661" |
| Connection Bore Diameter (mm) | 22.00mm |
| Contact Surface Diameter Machine Side (Decimal Inch) | 1.8898" |
| Contact Surface Diameter Machine Side (mm) | 48.00mm |
| Tool Entering Angle ( Degree) | 88 Degree |
| Application | Facing |
| Cutter Pitch | Extra Fine Pitch |
| Hand | Right Hand |
| Insert Holding Method | Screw |
| Material | Steel |
| Number of Flutes | 7 |
| Number of Inserts | 7 |
