Features:
| EDP Number | TWE17324 |
| Max Depth of Cut (Decimal Inch) | 0.1181" |
| Max Depth of Cut (mm) | 3.00mm |
| Cutting Width (Decimal Inch) | 0.0787" |
| Cutting Width (mm) | 2.00mm |
| Cutting Width Minimum (Decimal Inch) | 0.0787" |
| Cutting Width Minimum (mm) | 2.00mm |
| Cutting Width Maximum (Decimal Inch) | 0.0787" |
| Cutting Width Maximum (mm) | 2.00mm |
| Minimum Face Groove Diameter (Decimal Inch) | 0.2362'' |
| Minimum Face Groove Diameter (mm) | 6.00mm |
| Insert Length (Decimal Inch) | 0.6299" |
| Insert Length (mm) | 16.00mm |
| Tool Entering Angle ( Degree) | 95 Degree |
| Corner Radius (Decimal Inch) | 0.002" |
| Thickness (decimal Inch) | 3/32" |
| Thickness (mm) | 2.38mm |
| Application | Micro Face Grooving |
| Coating Process | Uncoated |
| Grooving Type | Face Grooving |
| Hand | Right Hand |
| Insert Grade | KW10 |
| Insert Holding Method | Screw |
| Material | Carbide |
| Number of Cutting Edges | 2 |
| Primary Workpiece Material | Non-Ferrous Materials (N) |
