Features:
| EDP Number | TWJ03514 |
| Max Depth of Cut (Decimal Inch) | 0.0984" |
| Max Depth of Cut (mm) | 2.50mm |
| Cutting Width (Decimal Inch) | 0.0591" |
| Cutting Width (mm) | 1.50mm |
| Cutting Width Minimum (Decimal Inch) | 0.0591" |
| Cutting Width Minimum (mm) | 1.50mm |
| Cutting Width Maximum (Decimal Inch) | 0.0591" |
| Cutting Width Maximum (mm) | 1.50mm |
| Minimum Face Groove Diameter (Decimal Inch) | 0.2362'' |
| Minimum Face Groove Diameter (mm) | 6.00mm |
| Connection Diameter (Decimal Inch) | 0.1969" |
| Connection Diameter (mm) | 5.00mm |
| Shank Height (Decimal Inch) | 0.1890" |
| Shank Height (mm) | 4.80mm |
| Tool Entering Angle ( Degree) | 90 Degree |
| Usable Length (Decimal Inch) | 0.5906" |
| Usable Length (mm) | 15.00mm |
| Corner Radius (Decimal Inch) | 0.002" |
| Corner Radius (mm) | 0.05mm |
| Application | Micro Internal Face Grooving |
| Coating Process | Uncoated |
| Cutter Pitch | PVD |
| Grooving Type | Internal Face Grooving |
| Hand | Right Hand |
| Insert Grade | GW05 |
| Insert Holding Method | Screw |
| Material | Carbide |
| Primary Workpiece Material | Stainless Steel (M) |
