Product Specifications
| Manufacturer Part Number | 14043750A |
| Diameter (Inch) | 7/16" |
| Diameter (Decimal Inch) | 0.438" |
| Ball Radius (Inch) | 7/32" |
| Ball Radius (Decimal Inch) | 0.219" |
| Shank Diameter (Inch) | 7/16" |
| Shank Diameter (Decimal Inch) | 0.438" |
| Overall Length (Inch) | 2-3/4" |
| Overall Length (Decimal Inch) | 2.750" |
| Length of Cut (Decimal Inch) | 1.000" |
| Helix Angle (Degree) | 30 Degree |
| Number of Flutes | 4 |
| Shank Type | Straight |
| Tool Construction | Solid |
| Type Of Cut | Roughing/Finishing |
| Coating | ALtima |
| Material | Carbide |
| Center Cutting | Yes |
| Product Type | Ball Nose End Mill |
| Country Of Origin | USA |
