M A Ford 30003700 | #63 Size x 0.037" Shank x 5/8" LOC x 1.500" OAL x 118 Degree Included Angle 2 Flute Uncoated Carbide Circuit Board Drill Bit

$27.13 $19.53
(You save $7.60)
Brand:
M A Ford
Diameter (Decimal Inch):
0.0370"
Shank Diameter (Decimal Inch):
0.0370"
Material:
Carbide
interval quantity:
1
SKU:
10095682
UPC:
697604301130
Weight:
1.23 LBS
Minimum Purchase:
1 unit
Shipping:
Calculated at Checkout
M A Ford 30003700 | #63 Size x 0.037" Shank x 5/8" LOC x 1.500" OAL x 118 Degree Included Angle 2 Flute Uncoated Carbide Circuit Board Drill Bit

Product Specifications
Manufacturer Part Number30003700
Diameter Size#63
Diameter (Decimal Inch)0.037"
Shank Diameter (Decimal Inch)0.037"
Overall Length (Inch)1-1/2"
Overall Length (Decimal Inch)1.500"
Length of Cut (Inch)5/8"
Length of Cut (Decimal Inch)0.625"
Helix Angle (Degree)35 Degree
Included Angle (Degree)118 Degree
Number of Flutes2
Shank TypeStraight
Tool ConstructionSolid
MaterialCarbide
Product TypeCircuit Board Drill Bit
Country Of OriginUSA
