Product Specifications
| Min Bore Diameter (Decimal Inch) | 0.4900" |
| Hand Direction | Left Hand |
| Finish/Coating | Uncoated |
| Shank Diameter (Inch) | 3/8" |
| Shank Diameter (Decimal Inch) | 0.3750" |
| Centerline Offset (Decimal Inch) | 0.2750" |
| Indexable K Angle | 93 Degree |
| Indexable Nomenclature | A06J SDUCL 2 |
| Insert Style | DCMT 21.51 |
| Micro 100 Insert Part | 50-1200 |
| Overall Length (Inch) | 4-1/2" |
| Overall Length (Decimal Inch) | 4.50" |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Micro 100
Toolholder Style:
A06J SDUCL 2
Minimum Bore Diameter (Decimal Inch):
0.4900"
Hand of Holder:
Left Hand
Overall Length (Inch):
4-1/2"
Overall Length (Decimal Inch):
4.50"
Shank Diameter (Inch):
3/8"
Shank Diameter (Decimal Inch):
0.3750"
Through Coolant:
Yes
Insert Compatibility:
DCMT 21.51
Ships:
From Partner Facility
