Product Specifications
| Min Bore Diameter (Inch) | 3/8" |
| Min Bore Diameter (Decimal Inch) | 0.3750" |
| Hand Direction | Right Hand |
| Finish/Coating | Uncoated |
| Max Bore Depth (Inch) | 3/4" |
| Max Bore Depth (Decimal Inch) | 0.750" |
| Projection (Decimal Inch) | 0.1000" |
| Shank Diameter (Inch) | 3/8" |
| Shank Diameter (Decimal Inch) | 0.3750" |
| Centerline Offset (Inch) | 3/16" |
| Centerline Offset (Decimal Inch) | 0.1875" |
| Corner Radius (Decimal Inch) | 0.005" |
| Face Dimension (Inch) | 3/16" |
| Face Dimension (Decimal Inch) | 0.188" |
| Neck Diameter (Decimal Inch) | 0.2700" |
| Overall Length (Inch) | 2-1/2" |
| Overall Length (Decimal Inch) | 2.50" |
| Split Length (Decimal Inch) | 0.245" |
| Tooth Width (Inch) | 1/8" |
| Tooth Width (Decimal Inch) | 0.1250" |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Micro 100
Material:
Carbide
Tool Bit Style:
LTR
Type:
Turning
Cutting Direction:
Right Hand
Shank Width/Diameter (Inch):
3/8"
Shank Width/Diameter (Decimal Inch):
0.3750"
Overall Length (Inch):
2-1/2"
Overall Length (Decimal Inch):
2.50"
Minimum Bore Diameter (Inch):
3/8"
Minimum Bore Diameter (Decimal Inch):
0.3750"
Maximum Bore Depth (Inch):
3/4"
Maximum Bore Depth (Decimal Inch):
0.750"
Flat:
0.125"
Finish/Coating:
Uncoated
Flat (Decimal Inch):
0.1250"
Ships:
From Partner Facility
