Product Specifications
| # Manufacturer Number | 1051520 |
| Diameter (Inch) | 25/64" |
| Shank (Inch) | 13/64"" |
| Flute Length (Inch) | 1-7/8" |
| Overall Length (Inch) | 3-1/4" |
| Drill Point Angle | 135 |
| Number of Flute | 2 |
| Material | HSS |
| Finish / Coating | Black Oxide |
| Coolant Through | No |
| Cutting Direction | Right |
| Flute Type | Conventional Spiral |
| Shank Type | Straight Shank |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Nachi
Drill Bit Size (Inch):
25/64";Drill Bit Size (Decimal Inch)=0.3906""
Drill Bit Size (mm):
9.92mm
Drill Point Angle:
135 Degree
Flute Length (Inch):
1-7/8";Flute Length (Decimal Inch)=1.8750""
Flute Length (mm):
47.63mm
Overall Length (Inch):
3-1/4";Overall Length (Decimal Inch)=3.2500""
Overall Length (mm):
82.55mm
Material:
HSS
Finish/Coating:
Black Oxide
Flute Type:
Conventional Spiral
Cutting Direction:
Conventional Spiral
Shank Type:
Straight Shank
Coolant Through:
No
