Product Specifications
| # Manufacturer Number | 1514536 |
| Shank Size | 0.5420" |
| Overall Length | 4.9210" |
| Number of Flutes | 4 |
| Finish / Coating | SG |
| Material | Powdered Metal |
| Cutting Direction | Right |
| Flute Type | Normal Spiral Flute |
| Thread Length | 1.2800" |
| Size-Pitch | M18 x 2.5 |
| Limit | D7 |
| Tap Type | Bottoming |
| Helix Direction | Right Hand |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Nachi
Thread Limit:
D7
Number of Flutes:
4
Material:
Powdered Metal
Finish/Coating:
SG
Overall Length (Inch):
4-35/38"
Overall Length (Decimal Inch):
4.9210"
Overall Length (mm):
124.99mm
interval quantity:
1
