Product Specifications
| Manufacturer Part Number | MXQ2650076W |
| Series | MXQNM-5 |
| Cutting Diameter (Decimal Inch) | 0.750" |
| Length of Cut (Decimal Inch) | 1.125" |
| Extended Length (Decimal Inch) | 3.125" |
| Shank Diameter (Decimal Inch) | 0.750" |
| Overall Length (Decimal Inch) | 6.000" |
| Corner Radius (Decimal Inch) | 0.030" |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Onsrud
Cutting Diameter (Decimal Inch):
0.7500"
Corner Radius (Decimal Inch):
0.0300"
Shank Diameter (Decimal Inch):
0.7500"
Helix Angle:
36 Degree
Material:
Solid Carbide
Number of Flutes:
5
Length of Cut (Decimal Inch):
1.1250"
Overall Length (Decimal Inch):
6.0000"
Shank Type:
Weldon
Through Coolant:
No
interval quantity:
1
