OSG 4100000611 | EXO No. 12 Thread Size x 0.160" Diameter x 0.250" Shank x 0.331" LOC x 3.000"OAL 3 Flute UNC 24 TPI EXO Coated Carbide 41000 Helical Flute Thread Mill

$319.75 $303.76
(You save $15.99)
Brand:
OSG
Length of Cut (Decimal Inch):
0.3310"
Number of Flutes:
3
Material:
Carbide
Finish/Coating:
EXO
interval quantity:
1
SKU:
25285722
UPC:
Weight:
0.08 LBS
Minimum Purchase:
1 unit
Shipping:
Free Shipping
OSG 4100000611 | EXO No. 12 Thread Size x 0.160" Diameter x 0.250" Shank x 0.331" LOC x 3.000"OAL 3 Flute UNC 24 TPI EXO Coated Carbide 41000 Helical Flute Thread Mill

The newly expanded EXOCARB thread mills now includes longer lengths, miniature mills and coolant-fed thread mills. All utilizing OSG's premium sub-micrograin carbide for hardness, helical flutes for free cutting action andEXO multi-layered coating for ultimate wear resistance and tool life.

Features & Benefits:

  • Optimized flute geometry: Reduced cutting forces
  • OSG's EXO multi-layered TiAlN coating: Improves wear resistance for extended tool life
  • Inch, Metric and Pipe: For internal inch, metric and pipe threads

Product Specifications
Manufacturer Part Number4100000611
Diameter (Decimal Inch)0.160"
Length of Cut (Decimal Inch)0.331"
Major Diameter (Decimal Inch)0.160"
Neck Length (Decimal Inch)0.374"
Number of Flutes3
Overall Length (Decimal Inch)3.000"
Shank Diameter (Decimal Inch)0.250"
Thread Size NumberNo. 12
CoatingEXO
MaterialCarbide
Helix DirectionRight Hand
Helix Angle (Degree)11-30 Degree
Series41000 Series
Product TypeHelical Flute Thread Mill
