Integral pocket type boring head size 32 with 90° approach angle and 2 micron adjusting accuracy for finishing within a diamerter range of 39 to 50mm, to hold a TC.. 16T3.. insert for longitudinal boring with and without shoulder.
Product Specifications
| EDP Number | 6760647 |
| Connection Size Code Machine Side | 32 |
| Connection Diameter (mm) | 20 mm |
| Connection Diameter (Inch) | 0.787" |
| Min Cutting Diameter (mm) | 39 mm |
| Max Cutting diameter (mm) | 50 mm |
| Functional Length (mm) | 45 mm |
| Cutting Edge Count | 1 |
| Max Body Diameter (mm) | 32 mm |
