Screw clamp boring bar for holding a triangular positive insert with an inscribed circle diameter of 9.525 mm, 3.97 mm thick (ISO designation TC.. 16T3.. ), left hand 90 Degree end cutting with off-set shank, steel with coolant hole, 32 mm diameter x 250 mm long for taper boring and longitudinal boring with and without shoulder.
Product Specifications
| EDP Number | 6761018 |
| Functional Width (mm) | |
| Coolant Supply Property | 1 |
| Inclination Angle | -10 |
| Maximum Axial Groove Outside Diameter (mm) | |
| Connection Diameter (mm) | 32 mm |
| Connection Diameter (Inch) | 1.26" |
| Shank Height (mm) | 30 mm |
| Shank Width (mm) | 30 mm |
| Minimum Bore Diameter (mm) | |
| Functional Length (mm) | 250 mm |
| Direction of Tool | Left |
| Country of origin | Czech Republic |
